CAPELLA High Bay LED Lighting Fixture 72W/96W/128W

CPL-096HM-00252-865-7016
CAPELLA High Bay LED Lighting Fixture 72W/96W/128W

128 W High Bay LED Lighting Fixture is a lighting unit with high power and various lenses designed for use in industrial facilities, warehouses, aircraft hangars and sports facilities with a height of 5 – 25 m. LED modules with high energy efficiency are used in the luminaires, which have a compact frame structure. It has 65°,110° options for different applications. It is classified according to energy consumption as well as different sizes and dimensions. Design and production can be done by determining different light and power values according to the ceiling height of the area to be illuminated.

Technical Specifications
  • Power: 72 W, 96 W, 128 W
  • Input Voltage: 200-240 V AC 50/60 HZ
  • Power Factor: >0,9
  • Efficacy: 132 Im/W
  • Total Flux: 16896 lm
  • Optic Beam Angle: 18°/40°/60°/25°-65°
  • Color Temperature (CCT): 5000 K
  • Color Rendering Index (CRI): 80+
  • IP Class: IP 65
  • Dimensions : 330x330x154 mm / 1200x115x85 mm
  • Weight: 7.9 kg
  • Warranty: 5 Years
Fields of Application

Stores

Factory

Gyms

Aircraft Hangars

Airports

Light Distribution

It has a large number of optical options for different application needs. Multiple optical options provide flexibility in lighting design.

18°

40°

60°

20°-70°

Other Specifications
  • Body: Aluminum Extrusion
  • Color Options: Black RAL 9005, Grey RAL 7016
  • Front Cover: Tempered Glass
  • Lens: PMMA
  • Light Source: LED
  • Impact Resistance: IK 08
  • Total Harmonic Distortion: <20%
  • CE Mark: Yes
  • RoHS Compliance: Yes
  • Lifespan: ≥60.000 Hours
  • Dimming Options: 1-10V, TRIAC, DALI
  • Operating Temperature: -25°/+55°C

Product Images
Testing Standards
  • EN 60598-1
  • EN 60598-2-5
  • EN 60529
  • IEC TR 62778
  • LM 79-18
Technical Drawing
Downloads

LDT File

Installation
Manual

Product Variations
Product CodePowerInput VoltageLuminous FluxLight AngleDimensionsWeight
CPL-072HM-00182-865-701672W200-240 V AC 50/60 HZ9504 lm60°330x330x154 mm7,9  kg
CPL-096HM-00252-865-701696W200-240 V AC 50/60 Hz12672 lm60°330x330x154 mm7,9  kg
CPL-128HM-00402-865-7016128W200-240 V AC 50/60 Hz16896 lm60°1200x115x85 mm7,9  kg
CPL-072HM-00602-865-701672W200-240 V AC 50/60 Hz9504 lm40°330x330x154 mm7,9  kg
CPL-072HM-25652-865-701696W200-240 V AC 50/60 Hz12672 lm40°330x330x154 mm7,9  kg
CPL-128HM-ASY12-865-7016128W200-240 V AC 50/60 Hz16896 lm40°1200x115x85 mm7,9  kg
