CASTOR DOB LED Floodlight is a lighting fixture designed to be used in park, garden, square, auto-park, building perimeter, walkway, landscape lighting, industrial facility environmental lighting to be mounted on poles with a height of 3 – 7 m. LED modules with high energy efficiency are used in luminaires with a compact case structure.
It is classified according to LED power as well as different sizes and dimensions. Different light distribution and power options are available according to the area to be illuminated, and design and production can be made according to the project needs.
- Power: 50W
- Luminous Flux: 4000 lm
- Operating Voltage: 220V-240V AC
- Input Frequency: 50-60Hz
- Power Factor: ≥0.9
- Efficiency Factor: >80+lm/W
- Lifetime: 60,000 Hours
- Degree of Protection: IP65-IP66(Optional)
- Operating Temperature: -25°/+55°C
- Fitting: IP66-Plastic PG9
- Dimensions: 181x213x04mm
Factories
Building
Circles
Park and Walking Ways
Parking Lots
It has a large number of optical options for different application needs. Multiple optical options provide flexibility in lighting design.
110°
- TS EN 60598
- TS EN 60529
- TS EN 62031
- TS EN 62262
- TS IEC TR 62471
- TS EN 62722-2-1
| Product Code | Power | Input Voltage | Light Angle | Luminous Flux | Dimensions | |
| CSR-030SM-01101-865 | 30W | 200-240-V AC 50-60 HZ | 110° | 2400 lm | 150x173x03mm | |
| CSR-050SM-01101-865 | 50W | 200-240-V AC 50-60 HZ | 110° | 4000 lm | 181x213x04mm | |
| CSR-100SM-01101-865 | 100W | 200-240-V AC 50-60 HZ | 110° | 8000 lm | 250x285x07mm | |
| CSR-150SM-01101-865 | 150W | 200-240-V AC 50-60 HZ | 110° | 12000 lm | 325x425x12mm | |
| CSR-200SM-01101-865 | 200W | 200-240-V AC 50-60 HZ | 110° | 16000 lm | 325x425x13mm | |
| CSR-300SM-01101-865 | 300W | 200-240-V AC 50-60 HZ | 110° | 24000 lm | 325x425x15mm |
