UAVs with lighting functions are widely used in industry. They are planned to be used 24/7 in various fields from the military sector to security forces and even search and rescue activities. In response to requests for illumination of larger areas and higher altitude, the G6LS model was developed based on the G5L model. With the G6LS model, you can fly smoothly and uninterruptedly at altitudes ranging from 5 meters to 50 meters. The maximum flight altitude is 50 meters due to the power cable.
The G6LS model has RTK technology that provides precise positioning capability. With this technology, positioning with centimeter precision can be provided. The G6LS model can respond to requests to work at an altitude/altitude of 4500 meters. Thanks to its 720W lighting capability, wide area scanning can be done more easily. Of the four 180W lighting modules under the drone, 2 of them can be directed to the desired area via the remote control.
It provides one-handed control and management with its specially designed remote control without the need for a professional UAV pilot. You can fly uninterruptedly at any point where you provide mains voltage. In case of emergency or power failure, the battery in the power unit will automatically ensure the safe landing of the UAV.
- Product Name: G6LS
- Centimeter Precise Positioning: RTK Technology
- Flight Altitude (m): 50m
- Automatic Take-off: No
- Automatic Landing: Yes
- Emergency Landing Mode: Yes, Automatic
- Take-off Weight(gr): 1430gr
- Dimension (mm): 296*296*203
- Wind – Rain Class: Class7 (13,9῀17,1m/sn) – Class10 (10L/sn)
- Maximum Working Height (Altitude) Operation Possibility: 4500 m
- Working Temperature (°C): -20°C – +50°C
- Lighting Unit Power (W): 720W
- Lighting Source: Power LED
- Correlated Color Temperature (CCT): 6500K
- Color Rendering Index: +70
- Lighting Area: >6000m2
- Remote Controller Communication Frequency (Ghz): 2.4Ghz
- Remote Control Communication Distance: <500m
- Channel Number: 32
- Input Voltage (AC): 220-240V, AC 50/60Hz
- Max. Power (W): 1250W
- Assembly Time / Working Area: 5min / 5m²
- Weight : 27 kg
- Dimension :760*540*400 cm
- Reel Winding – Release: ✓, Automatic – Manual
| Product Code | Power | Input Voltage | CCT/CRI | Take-Off Weight | Flight Time | Dimensions | Wire Length |
| G6LS-04-RW-32-TET-50 | 720W | 220 VAC 50-60 Hz / LiPo | 6500K / 70 CRI | 1430gr | 24h | L65x W30 x H42 cm | 50 m |
- Product average maximum power is 1.25 kW. You can use a generator or portable power station where there is no mains voltage.
- You can use the product for at least 1 hour with a 1250W Lithium Battery portable power station
- •You can also use it without interruption with a gasoline generator with a continuous power of at least 1.25kW. We recommend a generator due to price/performance and long-term use.
In the illumination test performed by taking our wired illuminated aircraft to an altitude of 5m (AGL), 687lux was obtained on the ground, 230lux was obtained at an altitude of 10m (AGL) and 80lux was obtained in the illumination measurement made while flying at an altitude of 15m (AGL). The visuals of the results of the measurements made with the Luxmeter at 5m, 10m and 15m are as follows.
