The Surface Mounted Circle Luminaire is a high-efficiency lighting solution produced with modern LED lighting technology. Available in different power options, including 6W, 12W, 18W, and 24W, this luminaire provides homogeneous lighting thanks to its wide light angle (110°).With an efficiency factor of 70 lm/W, it offers high energy efficiency, while its LED light source ensures long life and low energy consumption for an environmentally friendly use. The luminaire provides cool white light with a color temperature of 6500K, making it suitable for a wide range of applications, including offices, schools, hospitals, shopping malls, meeting rooms, laboratories, corridors, and hotels.
The Surface Mounted Circle Luminaire boasts a robust and durable structure, thanks to its aluminum extrusion body, and has IP20 protection class, making it suitable for indoor use. Operating with 170-265 V AC input voltage, the product has >0.5% power factor and <15% total harmonic distortion rate. It is designed for safe use, with a maximum voltage withstand of 2kV, and provides natural and high-quality lighting with a >80 CRI (color accuracy) value.Translated with DeepL.com (free version)
- Body: Aluminum Extrusion
- IP Protection Class: IP 40
- Luminous Flux: 1680 lm
- Light Source: LED
- Test Standards: TS EN 60598TS, EN 60529, TS EN 62031TS, EN 62262, TS IEC TR 62471TS, EN 62722-2-1
- Power: 24W
- Effectiveness Factor: 70 Im/W
- CE Marking: Yes
- Optics: PMMA / PC
- Input Voltage: 170-265 V AC 50/60 Hz
- Total Harmonic Distortion:<%15
- Light Angle: 110°
- Power Factor: ≥ 0.5
- Max Tensile Strength: 2kV
- Color Temperature: 6500K
- Operating Temperature: -20° ~ +35°C
- Led Lifetime: L70 > 60.000 saat
- Drive Lifetime: Ta=50°C 50.000 saat
- CRI: 80 CRI
- Automation/DIM Compatibility: DALI, 1-10V, Phase Cut, BasicDIM Wireless
110°
| Product Code | Power | Input Voltage | CCT | Light Angle | Luminous Flux | Color | Usage Area |
|---|---|---|---|---|---|---|---|
| SUD-006SM-01101-865-9016 | 6 W | 170-265 V AC 50/60 Hz | 6500K | 110° | 420 lm | White | Surface Mounted |
| SUD-012SM-01101-865-9016 | 12 W | 170-265 V AC 50/60 Hz | 6500K | 110° | 840 lm | White | Surface Mounted |
| SUD-018SM-01101-865-9016 | 18 W | 170-265 V AC 50/60 Hz | 6500K | 110° | 1260 lm | White | Surface Mounted |
| SUD-024SM-01101-865-9016 | 24 W | 170-265 V AC 50/60 Hz | 6500K | 110° | 1680 lm | White | Surface Mounted |
